Dell PowerEdge R620
11,999,000VND
Hết hàng
Mô tả
PROCESSOR – 2 SOCKETS
- Intel® Xeon® processor E5-2600 or E5-2600 v2 product families
- 2 x Intel QuickPath Interconnect (QPI); 6.4 GT/s; 7.2 GT/s; 8.0 GT/s
Cache:
- 2.5MB per core
- Core options: 4, 6, 8, 10, 12
OPERATING SYSTEM
- Microsoft® Windows Server® 2012
- Microsoft Windows Server 2008 R2 SP1, x64 (includes Hyper-V®)
- Novell® SUSE® Linux Enterprise Server
- Red Hat® Enterprise Linux®
Virtualization options:
- Citrix® XenServer®
- VMware® vSphere® ESXi™
- Red Hat Enterprise Virtualization®
CHIPSET
- Intel® C602
MEMORY
- Up to 1.5TB
- Up to 1866MT/s DDR3
- 24 DIMM slots (12 DIMMs per CPU)
STORAGE
- Maximum internal storage:
- Up to 10TBHot-plug hard drive options:
- 2.5” PCIe SSD, SAS SSD, SATA SSD, SAS (15K, 10K), nearline SAS (7.2K), SATA (7.2K), SAS 512n (15K)
- Self-encrypting drives available
DRIVE BAYS
- Up to 10 2.5” hot-plug SAS, SATA, or SSD
- Up to 4 hot-plug 2.5” SAS, SATA, or SSD + two PCIe SSD
SLOTS
3 PCIe slots:
- Two x16 slots with x16 bandwidth, half-height, half-length
- One x16 slot with x8 bandwidth, half-height, half-length
- Note: ten-drive-bay configuration is available only with 3 PCIe slot option
2 PCIe slots:
- One x16 slot with x16 bandwidth, full-height, 3/4 length
- One x16 slot with x16 bandwidth (or x8 with one processor only), half-height, half-length
RAID
Internal controllers:
- PERC S110 (SW RAID)
- PERC H310
- PERC H710
- PERC H710P
External HBAs (RAID):
-
- PERC H810
External HBAs (non RAID):
- 6Gbps SAS HBA
COMMUNICATIONS
- Broadcom® 5720 quad-port 1GbE Base-T (no TOE or iSCSI offload)
- Intel I350 quad-port 1GbE Base-T (no TOE or iSCSI offload)
- Intel X540 dual-port 10GbE Base-T with 2 x 1GbE (FCoE capability enabled on the 10GbE ports)
- Broadcom 57800S dual-port 10GbE Base-T with 2 x 1GbE (TOE and iSCSI offload available on 10GbE ports)
- Broadcom 57800S dual-port 10GbE SFP+ with 2 x 1GbE (TOE and iSCSI offload available on 10GbE ports)
- Broadcom 57840S quad-port 10GbE SFP+ Rack NDC (NPAR1.0, SRIOV, DCB, iSCSI and FCoE offloads and CEM)
POWER
- Titanium efficiency, hot-plug redundant 750W power supply
- Platinum efficiency, hot-plug redundant 495W, 750W or 1100W power supplies
- Auto-ranging power supplies
AVAILABILITY
- High-efficiency, hot-plug, redundant power supplies
- DC power supplies
- Hot-plug hard drives
- TPM
- Dual internal SD support
- Hot-plug redundant fans
- Optional bezel
- Luggage tag
- ECC memory
- Interactive LCD screen
- Extended thermal support
- ENERGY STAR® compliant
- Extended power range
- Switch Agnostic Partitioning (SWAP)
CHASSIS
- 1U Rack
MANAGEMENT
Remote management:
- iDRAC7 with Lifecycle Controller
- iDRAC7 Express (default)
- iDRAC7 Enterprise (upgrade)
- 8GB vFlash media (upgrade)
- 16GB vFlash media (upgrade)
Systems management:
- IPMI 2.0 compliant
- Dell OpenManage™ Essentials
- Dell OpenManage Power Center
- Dell OpenManage Connections:
- Dell OpenManage Integration Suite for Microsoft® System Center
- Dell plug-in for VMware® vCenter™
- HP Operations Manager
- IBM Tivoli® Netcool®
- CA Network and Systems Management
RACK SUPPORT
- ReadyRails II sliding rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded hole racks, with support for optional tool-less cable management arm
- ReadyRails static rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded and 2-post (Telco) racks
